High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment

Produkt-Details

Herkunftsort: Guangdong, China

Markenname: YUSH

Zahlungs-u. Verschiffen-Ausdrücke

Min Bestellmenge: 1 Satz

Preis: $17,000 / set

Beste Preis erhalten

Produkt-Details

Beschreibung des Produkts

Hervorheben:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                automatic COB PCB depaneling machine, high-precision COB board processing equipment, professional COB PCB assembly machine


Gewicht:	300 KG	Leistung:	10 kW
Stromspannung:	220V, 110V	Modell:	YSV-4A
Klingengröße:	20043,56mm	Arbeitsdruck:	0,5 ~ 0,8 mPa
Schnittbreite:	Maximale 200mm	V-geschnittene Stärke:	Ein Drittel der Plattendicke
Klingenmaterial:	Importierter, hochwertiger Schnellarbeitsstahl, titanbeschichtet	Leistung:	150W
Schneidebretter:	Glasfaserplatte, FR4-Platte, Aluminiumsubstrat, Kupfersubstrat	Fütterungsstruktur:	Präzisions-Pneumatikmodul
Positionierung:	Positionierung der V-Schnittlinie, Bildschirm zeigt Vorschubdaten an	Mikrostress:	Ungefähr 200
Schnitt des Anschlags:	unter 2mm

Gewicht:	300 KG
Leistung:	10 kW
Stromspannung:	220V, 110V
Modell:	YSV-4A
Klingengröße:	20043,56mm
Arbeitsdruck:	0,5 ~ 0,8 mPa
Schnittbreite:	Maximale 200mm
V-geschnittene Stärke:	Ein Drittel der Plattendicke
Klingenmaterial:	Importierter, hochwertiger Schnellarbeitsstahl, titanbeschichtet
Leistung:	150W
Schneidebretter:	Glasfaserplatte, FR4-Platte, Aluminiumsubstrat, Kupfersubstrat
Fütterungsstruktur:	Präzisions-Pneumatikmodul
Positionierung:	Positionierung der V-Schnittlinie, Bildschirm zeigt Vorschubdaten an
Mikrostress:	Ungefähr 200
Schnitt des Anschlags:	unter 2mm

High-Precision Automatic COB Board Processing Machine | Professional COB PCB Assembly & Handling Equipment

High-Precision Automatic COB Board Processing Machine

Professional COB PCB Assembly & Handling Equipment designed for efficient and precise board processing operations.

Key Features

Microcomputer-controlled automatic board feeding system specifically developed for COB light source PCB cutting
Versatile cutting capability for various COB substrates, bulb LED aluminum substrates, and ceramic plates
5-6 times faster processing efficiency compared to traditional board machines
Minimal component stress (approximately 200) during cutting to prevent tin cracking and protect precision parts
Gas hybrid design with double straight knife slitting for precision PCB board division
Scythe work mechanism suitable for various thickness MCPCB with cutting stroke below 2mm
Anti-dwelling structure design ensuring operational safety

Technical Specifications

Model	YSV-4A
Weight	230KG
Blade Size	200×43.5×6mm (Straight knife)
Voltage	220V
Working Pressure	0.5~0.8Mpa
Cutting Width	Max 200mm
V-cut Thickness	One third of plate thickness
Blades Material	Imported high-quality high-speed steel, titanium coated
Power	150W
Cutting Boards	Fiberglass board, FR4 board, aluminum substrate, copper substrate
Feeding Structure	Precision pneumatic module
Positioning	V-cut line positioning with screen display of feed data

Manufacturer Information

YUSH Electronic Technology Co., Ltd was founded in 2004 and is located in Jiangsu, China's world manufacturing hub. The company specializes in professional PCB separator and PCB depaneling electronic equipment machinery. YUSH maintains advanced production and processing equipment with an experienced development and manufacturing team, half of whom have over 10 years of experience in the electronic equipment industry. Since 2004, the company has focused on developing and manufacturing PCB separators and depaneling machines, emphasizing product quality, safety, and innovation. YUSH produces high-quality, stable performance, cost-effective products that improve production yields, increase productivity, and enhance customer market competitiveness. The product line includes various PCB separating types with manual, motor-driven, pneumatic-driven, mold punching, and milling cutter router options. With good quality and reasonable pricing, YUSH serves customers worldwide and has become one of China's largest PCB separator production bases.
